Batwing and Cobra Driving Lights Help

I just added a Memphis Shades Batwing with the Trigger Lock mount. I have a set of Cobra driving lights on my 06 Vulcan. Everything fits but now my driving lights are pointed down and pretty much worthless. I cannot raise them up enough because of hitting the wing. Anyone have a Batwing and Cobra driving light? If so, do you have this issus and are you living with it or have you learned a trick to correct. Any help would be great.

Forest
GySgt USMC (Ret)
PGR Member

06 Vulcan Classic
Memphis Shades Batwing
Kaw Gel Seat W/Comfort Zone Backrest (Mod,No more Gel)
Corbra Lightbar (Mod)
Mutazu RS hard bags
Givi E55 Tech Trunk
Cobra Luggage rack.
Highway bar with foot pegs
Kuryakyn Triple Whammy
STREET FX ElectroPods LED Brake Lights
Wolo Bad boy Horn
Custom Flag mounts
LED 4 Way Flasher
5' handlebar Riser
Fully DeBaffeled Stock Pipes
Cobra Fi200r
Cobra PowerFlo
TheRealForest is offline
Sponsored Links
Advertisement

post #2 of 13 (permalink) Old 11-17-2012, 11:28 AM
Senior Member

Join Date: May 2012
Location: Eugene Or.
Posts: 365
I put 2 washers between the lightbar and lower triple clamp, that gave me enough clearance to aim the spots just below where the headlight shined. I did also have to jockey the position of the batwing a little. Another option would be to elongate the spotlight mounting holes, it wouldn't take very much at all.
Cyclesarge is offline
post #3 of 13 (permalink) Old 11-17-2012, 12:31 PM Thread Starter
Member

TheRealForest's Avatar

Join Date: Jun 2012
Location: Charlotte NC (East Side)
Posts: 40
Garage
Thanks for the reply Sarge. I tried the washers but still didn't give me enough to get the light at the spot I wanted them. So I placed new holes in the bar about 1/2 over and a 1/4 forward. Now I have plenty of space to point them where I like and enough clearance so they won't rub the shield. Picked up a couple of chrome plugs that covewr the screws of a bathroom faucets to plug the old holes.

Now that's done the next mod will be to add the Vulcan emblem to the wing.

This picture is before doing the mod to the lightbar
Attached Thumbnails
Click image for larger version

Name:	K9_w_Wing.jpg
Views:	145
Size:	102.2 KB
ID:	14237

Forest
GySgt USMC (Ret)
PGR Member

06 Vulcan Classic
Memphis Shades Batwing
Kaw Gel Seat W/Comfort Zone Backrest (Mod,No more Gel)
Corbra Lightbar (Mod)
Mutazu RS hard bags
Givi E55 Tech Trunk
Cobra Luggage rack.
Highway bar with foot pegs
Kuryakyn Triple Whammy
STREET FX ElectroPods LED Brake Lights
Wolo Bad boy Horn
Custom Flag mounts
LED 4 Way Flasher
5' handlebar Riser
Fully DeBaffeled Stock Pipes
Cobra Fi200r
Cobra PowerFlo

Last edited by TheRealForest; 11-17-2012 at 12:59 PM. Reason: Note on picture
TheRealForest is offline
post #4 of 13 (permalink) Old 11-19-2012, 09:45 PM
Lifetime Premium

whiting57's Avatar

Join Date: Dec 2009
Location: Simcoe Ontario Canada
Posts: 3,412
I also put a small adhesive rubber grummet on the fairing behind each light to solve any vibration / scuffing (scratch) issues.


As i flipped into 5th, i couldnt remember a damn thing she said

2009 Classic LT Bagger... Batwing Fairing, Metzler 200 rear, Mutazu Hard Bags, Denray Hitch, Mustang Seat, Piggybacker Trailer.

2010 Custom [I] ... traded on a 2015 Ninja 650 Abs

Last edited by whiting57; 11-19-2012 at 09:48 PM.
whiting57 is offline
post #5 of 13 (permalink) Old 11-19-2012, 10:11 PM
Senior Member

Comanche's Avatar

Join Date: Nov 2012
Location: Arizona
Posts: 346
Garage
The batwing looks sweet but I only have one question. How is your overall visibility?

It ain't about where you live; it's about how you live. So, ride to live, Bruh.
Comanche is offline
post #6 of 13 (permalink) Old 11-20-2012, 01:00 AM
Lifetime Premium

bosco's Avatar

Join Date: Nov 2011
Location: Temescal Valley, CA
Posts: 1,335
Garage
Great info guys. I have been looking at the batwing from MS and wasn't sure it would fit with my cobra lightbar. Big thanks...

"Freedom is Loving what you do, and the ability to Pursue It!"

2010 900 Classic
bosco is offline
post #7 of 13 (permalink) Old 11-20-2012, 06:10 AM Thread Starter
Member

TheRealForest's Avatar

Join Date: Jun 2012
Location: Charlotte NC (East Side)
Posts: 40
Garage
When I get chance and good light I will take close up picture of the new holes I drilled in my bar how much clearance I have between them and the wing. With the plugs I put in them you really have to look hard to see them and if you dont know you cannot tell the lights have been moved. With the new placement I don't have to worry about the lights hitting or rubbing at all.

As for the visibility, I have no issues with mine. I have a 9 inch windshield so I'm looking right over the top the windshield. The top half of my shield is back but does not hinder my visibility at all.
Attached Thumbnails
Click image for larger version

Name:	K9_w_Wing2.jpg
Views:	98
Size:	96.8 KB
ID:	14278

Forest
GySgt USMC (Ret)
PGR Member

06 Vulcan Classic
Memphis Shades Batwing
Kaw Gel Seat W/Comfort Zone Backrest (Mod,No more Gel)
Corbra Lightbar (Mod)
Mutazu RS hard bags
Givi E55 Tech Trunk
Cobra Luggage rack.
Highway bar with foot pegs
Kuryakyn Triple Whammy
STREET FX ElectroPods LED Brake Lights
Wolo Bad boy Horn
Custom Flag mounts
LED 4 Way Flasher
5' handlebar Riser
Fully DeBaffeled Stock Pipes
Cobra Fi200r
Cobra PowerFlo
TheRealForest is offline
post #8 of 13 (permalink) Old 11-20-2012, 07:35 AM
Top Contributor

Graybush's Avatar

Join Date: Apr 2010
Location: Pensacola, FL
Posts: 1,049
Quote:
Originally Posted by Comanche View Post
The batwing looks sweet but I only have one question. How is your overall visibility?
I posted last night but thought I misread the question so I deleted it. I guess I wasn't too far off so here it is again.

Here's a picture that shows to show what it looks like from where I sit.



And here's one taken while riding. The camera is mounted on top of my helmet so the point of view is higher. The top of the windshield comes to my upper lip/tip of nose area.


2014 Triumph Tiger Explorer
2008 Yamaha XT250
2005 Honda CRF70F
War Eagle
Graybush is offline
post #9 of 13 (permalink) Old 11-20-2012, 10:14 AM
Senior Member

Comanche's Avatar

Join Date: Nov 2012
Location: Arizona
Posts: 346
Garage
Quote:
Originally Posted by Graybush View Post
I posted last night but thought I misread the question so I deleted it. I guess I wasn't too far off so here it is again.

Here's a picture that shows to show what it looks like from where I sit.



And here's one taken while riding. The camera is mounted on top of my helmet so the point of view is higher. The top of the windshield comes to my upper lip/tip of nose area.


Thanks for that point of view, Graybush.

It ain't about where you live; it's about how you live. So, ride to live, Bruh.
Comanche is offline
post #10 of 13 (permalink) Old 11-20-2012, 01:51 PM Thread Starter
Member

TheRealForest's Avatar

Join Date: Jun 2012
Location: Charlotte NC (East Side)
Posts: 40
Garage
Took a couple of pictures of the wing and the mod to the light bar during lunch. I pull the Plug I had in the hole out so it can be see better. Also you can see the clearance in the other pic between the light and the faring.
Attached Thumbnails
Click image for larger version

Name:	K9_Cobra_LB2.jpg
Views:	143
Size:	89.6 KB
ID:	14288   Click image for larger version

Name:	K9_Cobra_LB3.jpg
Views:	145
Size:	84.6 KB
ID:	14289   Click image for larger version

Name:	K9_Cobra_LB1.jpg
Views:	155
Size:	97.4 KB
ID:	14290

Forest
GySgt USMC (Ret)
PGR Member

06 Vulcan Classic
Memphis Shades Batwing
Kaw Gel Seat W/Comfort Zone Backrest (Mod,No more Gel)
Corbra Lightbar (Mod)
Mutazu RS hard bags
Givi E55 Tech Trunk
Cobra Luggage rack.
Highway bar with foot pegs
Kuryakyn Triple Whammy
STREET FX ElectroPods LED Brake Lights
Wolo Bad boy Horn
Custom Flag mounts
LED 4 Way Flasher
5' handlebar Riser
Fully DeBaffeled Stock Pipes
Cobra Fi200r
Cobra PowerFlo
TheRealForest is offline
